밀라크론 ELEKTRON 75

Milacron ELEKTRON 75

This Milacron ELEKTRON 75 was manufactured in 2011. It features a screw diameter of 18 to 32 mm and a clamp force of 750 kN. The machine dimensions are 4.36 × 1.42 × 1.95 m, and it weighs 4700 kg. If you are looking to get high-quality injection moulding capabilities, consider the Milacron ELEKTRON 75 machine we have for sale. Contact us for more information about this machine.

Additional information

• Clamp Force: 750 kN
• Injection Unit: 300
• Screw Diameter (mm): A 18 / B 25 / C 32
• Injection Pressure (bar): A 2500 / B 1943 / C 1488
• Shot Volume (cm³): A 103 / B 140 / C 183
• Shot Weight (PS g): A 113 / B 154 / C 201
• Injection Rate (cm³/s): A 117 / B 159 / C 208
• Screw Stroke (mm): 165
• Screw L/D Ratio: 25
• Plasticizing Capacity (g/s): A 9.2 / B 11.2 / C 11.2
Rsdpfxjx D N D Ds Ah Dop
• Screw Speed (rpm): 125
• Tie Bar Distance: 575 × 570 mm
• Platen Size: 750 × 765 mm
• Min Mould Height: 250 mm
• Max Mould Height: 480 mm
• Opening Stroke: 320 mm
• Max Daylight: 800 mm
• Ejector Stroke: 150 mm
• Ejector Force (kN): 25
• Mould Platen Hole Spacing: 405 × 380 mm
• Mould Weight Max (kg): 400
• Number of Core Pullers: 4 + 1
• Nozzle Radius: R = 300 mm
• Nozzle Orifice: Ø 48 mm
• Hydraulic Oil Capacity: 97 / 130 L
• Thread Size for Mounting: M10

Dimensions
Machine Depth 4360 mm
