CNC 절곡기 및 판금절단기 콤비.

OSTERBERGER KBA

KBA - Combined CNC-controlled press brake / guillotine shear
Super-compact machine with a very small footprint.

Maximum cutting length: 3,020 mm or 2,020 mm
Rated cutting capacity: 6 mm steel sheet / ST 40
Cutting angle: 1°30″
Backgauge for the shear station – adjustment range: 750 mm
Table height: 750 mm

Maximum bending length between side frames: 3,550 mm or 2,505 mm
Maximum pressing force: 1,000 kN
Working height for bending: only 1,230 mm
Stroke range (bending station): 175 mm
Maximum installation height (bending station): 350 mm
Backgauge adjustment range (bending station): 750 mm

Dimensions including operator’s pendant: 4.25 or 3.25 m x 1.82 m x H 2.8 m
Required floor space: 3.85 or 2.85 x 1.82 m
Drive power: 10 kW
Weight: 9,000 kg or 7,500 kg

Equipment:
- CNC control with touchscreen and 10” colour display, graphical user interface, and automatic bending angle calculation
- 1 set of press brake tools (bending punch + four-way reversible die)
- Sheet metal supports for the press brake station
- 90° angle stop for the guillotine shear with 1 m length
- Bending station working area safeguarding via light barriers, rear area safeguarded by lateral safety guards and light barriers

Optional:
- Front bending area guarding by PILZ® camera monitoring
Pedpfx Aeyhzlteb Esgi
- Rotatable angle stop
