Sonstige/Other Gremac e1 Radmobile Trommelsiebanlage

GREMAC e1 trommel screen

Tandem chassis / axles
2x kg ( permissible total weight)
kg empty weight without aggregate
Overrun brake
Vehicle lighting according to StVzO
TÜV acceptance

Drum
length: mm
Diameter: mm
4,0 kW electric drive
speed adjustable with frequency converter
driving screw
adjustable cleaning brush

hopper with conveyor belt
rubber belt with chevron profile
0,75 kW electric drive
speed adjustable with frequency converter
Gsdpfel Hbcfex Ag Roua

Fine grain collecting belt
Movable suspension
Rubber belt in smooth design
1,5 kW electric drive
Speed adjustable with frequency converter

Fine grain belt
Movable suspension
Rubber belt with chevron profile
2,2 kW electric drive
Speed adjustable with frequency converter
25 angles of inclination
Manual winch for angle adjustment

Over-grain stockpile conveyor
Movable suspension
Rubber belt with chevron profile
1,5 kW electric drive
Speed adjustable with frequency converter
25 angles of inclination
Manual winch for angle adjustment

Control system
PLC Siemens Logo
Control panel with buttons and potentiometers
400V load circuit
24V control circuit
Main switch
Ceekon 16A socket
EMERGENCY OFF relay
Without generator

Cladding
Hot galvanized frame parts
painted drum
cladding powder coated in RAL7005 and 5018

Further information

Purpose: construction, General condition: very good, Technical condition: very good, Visual condition: very good, Delivery conditions: EXW,
