원통형 연삭기 - 범용

STUDER S21 lean CNC

centre height 125 mm
centre distance 400 mm
Control FANUC 21i
Capstan diameter max. 406 mm
wheel dimensions 406 x 127 x 40 mm
workpiece weight 30 kg
longitudinal slide -travel 483 mm
cross slide - travel 254 mm
total power requirement max. 20 kVA
weight of the machine ca. 4,0 t
dimensions of the machine ca. 3,0 x 2,0 x 2,1 m
including 2 Pcs. internal grinding spindle
incl. B axis 1° Hirt, controlled
incl. C-axis
Gjdpfx Agjxwdwfe Rjua
incl. Quick-Set Probe
including Sensitron
including Magnetic Jaw
including hydraulically foldable dresser
including other small accessories
including documentation

without a coolant system, as it was previously connected to a central unit


Power On hours approx. 71,000 h
Spindle hours approx. 25,900 h
