TRUMPF TrumaBend V 1300

TRUMPF TrumaBend V 1300

This 6-axis TRUMPF TrumaBend V 1300 was manufactured in 2005. It features a press force of 1300 kN and a bending length of 3230 mm, making it suitable for various bending applications. The machine has a robust weight of 10,200 kg and offers a maximum backgauge range of 860 mm. If you are looking to get high-quality bending capabilities, consider the TRUMPF TrumaBend V 1300 press brake we have for sale. Contact us for further details.

• Free pillar passage: 2690 mm
• Throat depth: 420 mm
• Table width: 120 mm
• Installation height: 385 mm (Standard) / 615 mm (Extended Height)
• Working height (with 100 mm die): 1050 mm
• Beam stroke: 215 mm (Standard) / 445 mm (Extended Height)
• Beam positioning accuracy: 0.005 mm
• Beam inclination: ±10 mm
• Y-axis rapid/working/return speed: 220 / 0.1–10 / 220 mm/s
• X-axis travel: 600 mm; positioning accuracy: 0.04 mm; speed: 0–1000 mm/s; max backgauge range (X): 860 mm
• R-axis travel: 250 mm; positioning accuracy: 0.08 mm; speed: 0–330 mm/s
• Z-axis travel: 2400 mm; positioning accuracy: 1.00 mm; speed: 0–1000 mm/s
• I-axis: Lower tool displacement (pneumatic or CNC-controlled)
• V-axis (crowning): Manual or CNC-controlled
• Control: TASC 6000 with 15" TFT screen
• Storage: 2 × 40 GB hard drives
• Interfaces: Parallel, RS232, USB, Ethernet
• Electrical connection (connected load): 23 kVA
• Pneumatic connection: 6 ± 1 bar
• Hydraulic oil volume: 208 liters
• Input voltage (measured): 401 V (target 400 V)
• Control voltage (measured): 25.70 V (target 24 V)
• After-run travel/time: 5 mm (at 220 mm/s) / 33 ms
• Total machine hours (05.03.2026): 57,547 h
• Total hydraulic hours (05.03.2026): 30,627 h

Additional equipment

Hsdpey A Inbjfx Ag Reff
• BendGuard safety system
• Foot switch included
• Optional available: ACB Measuring Tools
• The Hydraluk cylinder is slightly leaking but still works

Technical Specification
Bending Length 3230 mm
