HOMAG WEEKE Profi BMG 611/60/15/F/AP
HOMAG WEEKE Profi BMG 611/60/15/F/AP

Name: HOMAG WEEKE Profi BMG 611/60/15/F/AP
Brand: HOMAG WEEKE
Availability: InStock

제조 연도

2012

상태

중고

위치

네덜란드

HOMAG WEEKE Profi BMG 611/60/15/F/AP HOMAG WEEKE Profi BMG 611/60/15/F/AP

지도 표시

기계 정보

기계 명칭:: HOMAG WEEKE Profi BMG 611/60/15/F/AP

제조업체:: HOMAG WEEKE

모델:: Profi BMG 611/60/15/F/AP

제조 연도:: 2012

상태:: 사용 준비됨 (중고)

가격 및 위치

위치:: , 네덜란드

전화하기

기술 세부 사항

X축 이동 거리:: 6,175 mm

Y축 이동 거리:: 1,900 mm

Z축 이동 거리:: 300 mm

축 수:: 3

총 높이:: 300 mm

스핀들 모터 출력:: 15,000 와트

스핀들 속도 (최대):: 24,000 rpm

제안 세부 정보

광고 ID:: A20984762

참조 번호:: NL-CNC-HOM-2012-00001

업데이트:: 마지막 업데이트: 19.02.2026

설명

This 3-axis HOMAG WEEKE Profi BMG 611/60/15/F/AP was manufactured in 2012. A CNC Wood Machining Centre designed for precision and efficiency in woodworking applications. Consider the opportunity to buy this HOMAG WEEKE Profi BMG 611/60/15/F/AP CNC Wood Machining Centre. Contact us for further details regarding this machine.

Additional equipment

• Safety devices: Laser, bumper

• Torque support: Yes

• Grooving saw: 90° pivoting

• Vertical drilling spindles: 17

• Horizontal X drilling spindles: 2

• Horizontal Y drilling spindles: 2

• Liquid-cooled milling spindle: Yes

• Closed drag chain: Yes

• Handheld terminal: Yes

• HOMAG SaveScan: Yes

Machine Benefits

Technical Machine Benefits

• High spindle speed

• Comprehensive safety features

• Independent z-axes: 2

• 4th axis: yes

• 5th axis: 5-axis spindle

• Workpiece support aids available

• Machine table: console table

• Number of consoles: 12
Kedpfxeyap S Ie Anvelr

• Features: automatic table positioning, homag ap table, two stop rows

Extra Information

Conformity marking: CE mark

Dimensions
Machine Depth 6175 mm
