복사기 및 연삭기 PADE 2+2

PADE UINZE 2+2

COPY SHAPER and SANDER machine , automatic , model PADE UINZE 2+2
second hand machine
working condition : Excellent
CE mark : YES

the machine has been designed for the production of parts of tables , chairs , furniture , etc.
the machine executes shaping and sanding operations simultaneously on two sides of a workpiece , with the aid of a template prepared according to the desired shape
with accident prevention cabin as shown in the photo

machine composed by n.04 working units :
1+1 shaping units . motor power Hp 10 each one
1+1 shaping / sanding units . motor power each one Hp 5 / 6,5 ( 2 speeds )
Nodpfx Acszk I Egofodc
max. working width mm.350
max. workinh heigth mm.180
max. working length mm.2500
hydraulic carriage . pump motor power Hp 5,5
adjustable hydraulic carriage advance speed: 1:15 m/min.
hydraulic carriage return speed: 40 m/min.
volt. 380/50
total installed power Kw 30
weight kg. 3500
